Part #: INTFLEXKITTNDM5201

This product qualifies for quantity discount pricing

Quantity	Discount%	Discounted Base Price
2-5	5%	$3,531.14
6-20	10%	$3,345.29
21-250	15%	$3,159.44

Free FedEx Shipping and Volume Pricing

106 Years in Trailer parts Distribution

Summary

Tandem 10,400 lb. Dexter® Torflex® torsion axle kit with electric brakes on one axle, sixteen-inch ST23580R16E white spoke wheels and tires, a 2 5/16" ball a-frame 50° RAM® coupler, with matching RAM® a-frame jack.

Outside of Brackets

Hub Face Measurement (Minimum Overall Overhang 15" Maximum Overall Overhang 20") (Example outside bracket 60" hub face will be 75" to 80") (Maximum 95" hub face)

22.5° Down - No Load H 4.07" L 5.54" Full Load H 1.77" L 6.00"Shock Load H 0.60" L 5.88"

10° Down - No Load H 2.81" L 5.91" Full Load H -0.47" L 5.86" Shock Load H -0.65" L 5.49"

0° - No Load H - 1.77" L 6.00" Full Load H -0.53" L 5.54" Shock Load H -1.56" L 4.99"

10° Up - No Load H - 0.73" L 5.91" Full Load H -1.45" L 5.06" Shock Load H -2.38" L 4.33"

22.5° Up - No Load H -0.53" L 5.54" Full Load H -2.47" L 4.24" Shock Load H -3.22" L 3.33"

Painted

Galvanized - Will take 2-3 additional weeks to ship [Add $200.00]

Cambered, Brake Flange, E-Z Lube Spindle, Low Profile Mounting Bracket in Standard Orientation, No Pre-Wire

By selecting this box, you agree this is a custom-built to order Torflex trailer axle to the specifications provided on this order form. Once the order is placed the axle cannot be altered, changed, cancelled, or returned for any reason. If you have any questions before placing this order please email [email protected] or call 1-800-866-3336

Summary

Outside of Brackets
Hub Face Measurement (Minimum Overall Overhang 15" Maximum Overall Overhang 20") (Example outside bracket 60" hub face will be 75" to 80") (Maximum 95" hub face)
22.5° Down - No Load H 4.07" L 5.54" Full Load H 1.77" L 6.00"Shock Load H 0.60" L 5.88"
Painted
Cambered, Brake Flange, E-Z Lube Spindle, Low Profile Mounting Bracket in Standard Orientation, No Pre-Wire
By selecting this box, you agree this is a custom-built to order Torflex trailer axle to the specifications provided on this order form. Once the order is placed the axle cannot be altered, changed, cancelled, or returned for any reason. If you have any questions before placing this order please email [email protected] or call 1-800-866-3336

Base Price: $3,716.99

Customized Price: $3,716.99

Quantity

Description

You have selected the tandem 10,400 lb. Dexter® Torflex® torsion axle kit with electric brakes on one axle, sixteen-inch ST23580R16E white spoke wheels and tires, a 2 5/16" ball a-frame 50° RAM® coupler, with matching RAM® a-frame jack. We have many different lengths of axles for your trailer. We ask that you provide your desired outside frame width when placing your order. Below is a complete bill of materials for the trailer kit you have selected.

Bill of materials for selected tandem 10,400 lb. trailer kit:

(1) 5,200 lb. Dexter® Torflex® torsion axle with idler hubs (Some assembly required)
(1) 5,200 lb. Dexter® Torflex® torsion axle with electric brakes (Some assembly required)
(4) Sixteen-inch ST23580R16E white spoke wheels and tires
(1) Trailer light kit including taillights, clearance lights, license plate bracket, and wire with connection
(1) RAM 2 5/16" 50° A-frame coupler
(1) RAM A-frame jack
(2) Safety chains
(1) Breakaway kit with charger
(1) 7 Way trailer end connector
(40) 7 Way trailer cable
(50) 18" x 2" Reflective Conspicuity Tape Strips

Part Number: ASINTFLEXKITTNDM5201 | Total weight: 900 lb.
